Description
Certified 160L Ethanol Wash/Dry Centrifuge with Explosion Proof Motor and Controller
Notice to Customer: This unit has 4 lift points (one in each corner) and requires a forklift to lift it. It will also ship via freight only.
Industrial Centrifuges are used to separating liquids from solids and this style of centrifuge excels at alcohol extraction by forcefully separating the alcohol from the biomass.
Key Features:
Siemens Touch Screen Controller
Explosion Proof Controller Housing and Motor
Agitation and Spin Dry Modes
Max 1200 RPM with Gradual Speed Stepping
643 Separation Factor
Multiple Connection Ports/Sizes
High Polish Stainless Steel Components
Shock absorbing legs
Vacuum Jacket with Two 1" Tri-Clamp Fittings
Pre-wired and Tested for Easy Installation
*BVV Centrifuges are now available certified by PRV Engineers. Field visits/verification letters are an additional $4,000 + travel expenses.*
Specifications
Capacity 160L
Drum Dimensions 31.5" (800mm) Diameter x 12.6" (320mm) Depth
Speed 0-1200r/min
Weight 3307lbs (1500KG)
Exterior Dimensions 51.2" x 72.8" x 43.3" (1300 x 1850 x 1100mm)
Material
304 Stainless Steel
Motor Power
7.5KW Explosion Proof - 220v 60Hz 3 Phase
