POLYSCIENCE 7 LITER MX HEATED CIRCULATOR
Key Specifications:
- Controller Type: MX
- Display: 3.25" LCD
- Working Temperature Range C: Ambient +10 to 135C
- Temperature Stability C: +/- 0.07C
- Temperature Calibration Capability: 1-point
- Working access (L x W x D cm): 15.7 x 14.2 x 12.7 cm
- Pump Type: Pressure
- Flammability Class (DIN 12876-1): I (NFL)
Key Features:
- Large, universal icon and English Display
- On-screen prompts
- Single-point calibration capability
Common Specifications:
- Working Temperature Range F: Ambient +20 to 275F
- Working Temperature Range C: Ambient +10 to 135C
- Reservoir Capacity (gallons): 1.85
- Reservoir Capacity (liters): 7
- Reservoir/Tank Material: Stainless Steel
- Reservoir Cover: Included
- DuraTop: Yes
- LidDock: Yes
- Working Access (L x W x D inches): 6.18 x 5.59 x 5 in
- Working Access (L x W x D cm): 15.7 x 14.2 x 12.7 cm
- Temperature Stability F: +/- 0.13F
- Temperature Stability C: +/- 0.07C
- Display: 3.25" LCD
- Display Resolution (Set): 0.1
- Display Resolution (Read): 0.1
- Pump Type: Pressure
- Pump Speed: One
- Process Connections: 1/2" O.D. Barbed Tubes (multiple connections included)
- Flamability Class (DIN 12876-1): I (NFL)
- Over-Temperature Protection / Failsafe Heater Control: Yes
- Low Liquid Level Protection: Yes
- Reservoir Drain: Yes
- Cooling Coil: Yes
- Maximum Ambient Temperature F: 95F
- Maximum Ambient Temperature C: 35C
- Overall Dimensions (L x W x H inches): 19.6 x 8.7 x 17.2 in
- Overall Dimensions (L x W x H cm): 49.9 x 22.1 x 43.7 cm
- Environmental Compliance: RoHS, WEEE
- Shipping Weight (pounds): 36.0
- Shipping Weight (kilograms): 16.3
60Hz Only:
- Part Number: MX07H135-A11B
- Maximum Pressure (psi): 2.3
- Maximum Pressure (bar): 0.16
- Maximum Pressure Flow Rate (gpm): 3.60
- Maximum Pressure Flow Rate (l/min): 13.5
- Included Hardware: Fitting Kit for External Applications
- Heater Wattage: 1100
- Electrical Requirements (VAC/Hz/Ph/A): 120/60/1/10
- Regulator Approvals: ETL
Operator's Manual:
(30 Day Limited Warranty: after this time period, any warranty issues must be resolved with the end supplier).
